► Any fiber-optic cable, also known as an optical-fiber cable, is an assembly similar to an electrical cable,
► but containing one or more optical fibers that are used to carry light.
► The optical fiber elements are typically individually coated with plastic layers and contained in a protective tube suitable for the environment where the cable is used.
► Different types of cable are used for different applications, for example,any state to state long distance telecommunication, or providing a high-speed data connection, Cable Tv Connection, Mobile Phone Communicationbetween different place
🔶
Attenuation Chart 🔶
| Frequencey (MHZ) |
Series 6 Maximum (db/100m.) |
Series 11 Maximum (db/100m.) |
|---|---|---|
| 5 | 1.90 | 1.25 |
| 55 | 5.25 | 1.25 |
| 83 | 6.40 | 3.15 |
| 187 | 9.35 | 3.87 |
| 211 | 10.00 | 5.74 |
| 250 | 10.82 | 6.23 |
| 300 | 11.64 | 6.72 |
| 350 | 12.63 | 7.36 |
| 250 | 13.61 | 7.94 |
| 400 | 1.90 | 8.53 |
| 450 | 14.43 | 9.02 |
| 500 | 15.09 | 9.51 |
| 550 | 16.08 | 9.97 |
| 600 | 16.73 | 10.43 |
| 750 | 18.54 | 11.97 |
| 865 | 20.01 | 13.05 |
| 1000 | 21.49 | 14.27 |
This information collected in CABLE ZONE
